/ Product advantages /
01
High-precision peeling
Through the precise positioning and clamping of logs by the clamping shaft, and the precise control of the peeling mechanism, the peeling machine with a clamp can achieve high-precision peeling processing. The logs can be easily peeled into veneers with uniform thickness and high surface flatness.
02
Efficient and stable
The structure design of the peeling machine with a clamping shaft is reasonable, and the transmission system is stable, which can ensure the stability of the equipment during high-speed rotation and long-term operation. At the same time, it has a high degree of automation, and the feeding system and the peeling mechanism can work together to achieve a continuous and efficient peeling process, greatly improving production efficiency, and is suitable for large-scale industrial production.
03
Wide range of applications
It can adapt to a variety of logs of different diameters and lengths. Whether it is a small-diameter log with a smaller diameter or a log with a larger diameter, the peeling machine with a clamping shaft can effectively clamp and peel by adjusting the spacing and clamping force of the clamping shaft.
/ Product Parameter /
Model | ALVA-VSVP-4FT-01 | ALVA-VSVP-D4FT-01 | ALVA-VSVP-D8FT-01 | ALVA-VSVP-8FT-01 | ALVA-VSVP-10FT-01 |
max. Diameter for log (mm) | Φ1500-2200 | Φ1500-2200 | Φ1500-2200 | Φ1500-2200 | Φ2200 |
peeling length (mm) | 1300 | 1300 | 2000-2600 | 2000-2600 | 600-3300 |
peeling thickness (mm) | 0.5-3.0 | 0.2-15.0 | 0.2-10.0 | 0.2-2.8 | 0.2-2.6 |
machine dimension (mm) | 4700*2200*2400 | 6200*2500*2400 | 7500*3000*3400 | 6000*3000*2600 | 6550*2300*2600 |
machine weight (kg) | 6500/7500 | 16000 | 19000 | 7500/9000 | 9000/12000 |
machine installed power(kw) | 62.35kw | 71.1kw | 95.7kw | 35.55kw/68.55 | 77.45kw |
min motor(kw) | 22kw*1 / 45kw*1 (Siemens Bede) | 55kw*1 (Siemens Bede) | 75kw*1 (Siemens Bede) | 22kw*1 / 55kw*1 (Siemens Bede) | 30kw*1 / 55kw*1 (Siemens Bede) |
chuck tighting motor (kw) | 7.5kw*1 (servo motor) | 7.5kw*1 (servo motor) | 11kw*1 (Siemens Bede) | 1.5kw*1 (servo motor) | 5.5kw*1 (servo motor) |
quick go forward & back motor(kw) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) |
knife motor(kw) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | |
hydraulic motor(kw) | 0.75kw*1 (Siemens Bede) | 7.5kw*1 (Siemens Bede) | 7.5kw*1 (Siemens Bede) | 0.75kw*1 (Siemens Bede) | 0.75kw*1 (Siemens Bede) |
pressing roller motor (kw) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | 1.1kw*1 (Siemens Bede) | ||
hanging wood motor(optional) | x | 2t overhead crane 3.8kw | 3t overhead crane 5.3kw | 1.1kw*1 (Siemens Bede) | 3kw*2 Siemens Bede) |
remaining wood core diameter | 120mm | 120mm | 120mm | 90mm | 120mm |
/ Honor Display /
/ Customer Visiting /
![]() | ![]() | ![]() | ![]() | ![]() | ![]() |
![]() | ![]() | ![]() | ![]() | ![]() | ![]() |
![]() | ![]() | ![]() | ![]() | ![]() | ![]() |
/ Packaging & Shipping /
![]() | ![]() | ![]() |
![]() | ![]() | ![]() |
![]() | ![]() | ![]() |
/ FAQ/
Q1: Are you the manufacturer of the Wood Chipper?
A1: Yes, we are the direct manufacturer of the Wood Chipper. We design, produce, and test all our machines in-house, ensuring the highest quality and reliability. This also allows us to offer competitive prices and quick turnaround times for orders.
Q2: What are the main advantages of the Alva Wood Chipper?
A2: The Alva Wood Chipper is designed with advanced features such as dual crushing functions, adjustable screens for various particle sizes, and a widened feed port for easy material handling. Our machines are built with high-quality, wear-resistant materials and come with a 1-year warranty on core components. Additionally, we offer customizable solutions to meet specific client needs.
Q3: What kind of materials can the Wood Chipper process?
A3: Our Wood Chipper is capable of processing a wide range of materials, including small-diameter wood, bamboo, boards, and leftover wood after debarking. It is ideal for industries such as textile, papermaking, pulping, artificial board production, and biomass energy.
Q4: How long does it take to ship the Wood Chipper after placing an order?
A4: If the machine is in stock, we can ship within 3-5 business days. For custom orders, the production and shipping
process typically takes about 15-20 days. We prioritize quick delivery to ensure minimal downtime for our customers.
/ Why Choose Us?/
1. High-Quality Products
At Alva, we are committed to delivering top-notch wood processing machinery. Our Wood Chipper is designed with advanced features such as dual crushing functions, adjustable screens for various particle sizes, and a widened feed port for easy material handling. We use high-grade materials like heat-treated alloy blades and imported bearings to ensure durability and long-lasting performance. Each machine undergoes rigorous testing before shipment to guarantee it meets our high standards.
2. Customized Solutions
We understand that every business has unique requirements. That’s why we offer non-standard customization options for our Wood Chippers. You can choose the appropriate shredder based on material size, characteristics, and output requirements. We also provide various feeding and discharging methods, customizable machine height, and a range of screen mesh sizes to meet your specific needs. Whether you need a machine for small-scale operations or large industrial use, we can tailor our products to fit your specifications.
3. Reliable Manufacturer
As a direct manufacturer, we design, produce, and test all our machines in-house. This allows us to offer competitive prices and quick turnaround times for orders. We have years of experience in the industry and a strong reputation both domestically and internationally. By choosing Alva, you are partnering with a reliable and trustworthy company that stands behind its products.
