High-Efficiency Biomass & Coal Boiler

Coal-fired (biomass) boilers can burn for a long time after filling coal once, and automatic control cycle heating does not require special personnel on duty. The boiler operation is worry-free and labor-saving. An automatic control device is added to automatically control the outlet water temperature and automatically stop setting the outlet water temperature. The combustion technology of reverse burning multi-return fireworks and self-winding is adopted. The flame burns from top to bottom and uses a draft fan to guide the flow direction. There are multiple returns up and down through the inner wall of the pipeline, and finally the smoke outlet is discharged. The temperature rises quickly and the thermal efficiency is good.

Quantity:
Availability:





Inquire Add to Basket

Related Products

Product Description

Alva coal-fired (biomass) boiler uses biomass fuel (such as crop straw, forestry waste, wood chips, etc.) as energy, and uses the heat released by its combustion to heat water or generate steam. It is an environmentally friendly thermal energy equipment with a thermal efficiency of more than 80%. It burns cleanly, emits less pollutants, has good environmental benefits, and can also achieve the recycling of biomass resources.

/ Product advantages /

01

Intelligent CNC

The boiler adopts fully automatic CNC, and the outlet water temperature can be adjusted, which saves worry and effort.

High-Efficiency Biomass & Coal Boiler

02

Draft fan

The combustion system is equipped with a rotating secondary feeding and air distribution technology, with large air volume, low noise and stable operation

03

Thickened plate die-casting furnace door

Die-casting, the furnace door is not afraid of high temperature

The appearance is simple and generous, and it is flexible to open

Good heating speed

Increased the length and number of heat absorption tubes

Thickened heating tubes to increase the heating speed

/ Product Parameter /

project	Boiler model
project	DZL0.5-0.7	DZL1-0.8	DZL1-1.0	DZL2-1.25	ZDL4-1.25
Rated evaporation capacity (t/h)	0.5	1	1	2	4
Rated working pressure (Mpa)	0.7	0.8	1	1.25	1.25
Rated steam temperature (°C)	171	175	184	194	194
Feed water temperature (C)	20	20	20	20	20
Heating area (m?)	22.5	32.4	42	80	104
Economizer(m°)	8.25	12.51	15	20	32.4
Effective area of grate (m²)	1.45	2.05	1.8	3	5865
Applicable fuel	Class ll andlll bituminous coal and biomass
Applicable amount of boiler fuel (kg/h)	88	170	146	289	546
Boiler thermal efficiency (%)	74	76.8	80	86	88
