Heavy-Duty Wood Disc Chipper Machine

The Alva disc chipper feeds the wood from the feed port. When it contacts the cutting blade, it is cut with the high-speed rotation of the cutting disc. The cut wood chips are sent out in the cutting chamber by the high-speed air flow generated by the fan blades on the cutting disc. In this process, the gap between the bottom knives can be adjusted to produce wood chips of different specifications and thicknesses. It is widely used in the preparation section of industrial production such as papermaking, particleboard, medium fiberboard, wood fiberboard plant, pulping plant, etc. It can also be used in a single wood chip production base and is also suitable for the processing of wood raw materials in the biomass energy industry.

Quantity:
Availability:





Inquire Add to Basket

Related Products

Product Description

1. High production efficiency: It has a high cutting speed and output. For example, some large disc chippers can produce more than ten tons or even more per hour.

2. Good quality of wood chips: It can make the length, thickness and thickness of the wood chips uniform, neat and uniform, with a high qualified rate of wood chips. The qualified rate of log wood chips is required to be greater than 98%, and the qualified rate of board skin is required to be greater than 99%.

3. Easy operation and maintenance: compact structure, reasonable layout, easy installation, convenient operation and maintenance, some models are also equipped with intelligent control systems, which can realize automatic operation.

4. Wide range of applications: It can cut bark, board skin and peeling machine scraps of multiple sizes, etc.

/ Product advantages /

01

Thickened material

Use thickened steel plate to create an ultra-thick steel body, making the machine more stable.

Heavy-Duty Wood Disc Chipper Machine

02

Widen the feed port, easily load materials, and improve work efficiency.

03

High-horsepower engine

Brand engine, fast heat dissipation and high speed, long-term work without burning the engine, diesel, gasoline, electric and other power options.

/ Product Parameter /

Model	ALVA-215	ALVA-216	ALVA-218	ALVA-2110	ALVA-2113	ALVA-2113	ALVA-6213
Output (t/h)	5~8	8~12	10~20	15~25	25~35	25~35	35~50
Number ofblades (pieces)	2 or3	2 or3	3 or 4 or 5	3 or 4 or 5	3 or 4 or 5	3 or4 or 5	4 or5 or 6
Main motor (kw)	45	55	110	132~160	220	220	315
Feeding motor(kw)	2.2-3	3.0-4	4.0-5	7.5-11	11	11	11
Rotor diameter(mm)	500	650	800	1000	1300	1300	1300
Feed port (mm)	180*400	240*540	310*680	500*1000	500*700	500*700	550*1480
Rotor speed(r/min)	590	590	650	500	500	500	500
Feeding speed(r/min)	38	38	38	38	38	38	38
Maximum rawmatenaldiameter (mm)	160	200	300	420	450	450	480
Wood chip size(mm)	20-35	20-35	20-35	20-35	20-35	7.5	20-35
Feed conveyormotor (kw)	2.2	4	4	11	11	11	11
Discharge rackmotor (kw)	2.2	3	5.5	5.5	7.5	7.5	7.5
Weight (kg)	2990	4070	7200	12500	14500	14500	18000
Overalldimensions(mm)	154012401020	198019501250	230021501500	385024482050	385024482050	385024482050	367033002050
